Strata 3D CX 7.5

Unlike some 3D applications, Strata 3D CX 7.5 gives you all of its 3D tools for one great price. Strata Design 3D CX is a professional-level 3D modeling and animation software for Mac and PC that delivers end-to-end power for the entire 3D design workflow. Quickly bring your ideas to life with a simplified learning curve, tight integration with Adobe Photoshop and award-winning rendering quality.

Strata Design 3D 7.5 is a powerful modeling and texturing upgrade, which includes many of the most requested features from long-time Strata Design 3D users. They have combined new UV texturing components that allow you to more easily visualize the exact layout and placement of your textures, with polygon manipulation features that provide a new level of control over your 3D objects, and added in some very useful import and export options to make version 7.5 more compatible with CAD programs and 3D printing services.

Strata 3D CX 7.5

This page will give you an idea of the key features of Strata 3D CX 7.5 and the system requirements of Strata 3D CX 7.5.

Take a look around.

Follow @QualityTexture

New Features in Strata 3D CX 7.5

Modeling Menu - New Entry

• Decimate

Poly Edit Mode - New Commands & Features

• Show Face Normals - Helps identify inverted normals, which can interfere with rendering and 3D printing.
• Select Perimeter
• Rotate Connected
• Split Edge
• Segment Edge Dialog - Splits an edge into a specific number of equal segments.
• Select UV Seam Edges - Selects any previously designated UV seams.
• Toggle UV Seam Edge - Toggles (on or off) one or more selected edges as UV seams - to designate unwrapping seams for Burn UV and UV edit mode.
• Color Coded UV Seams - Helps identify UV seam edges in poly edit mode.
• Move Commands: Move to Grid, Move to X, Y, or Z, Move Center to X, Y or Z.

UV Edit Mode - New Commands & Features

• Conform - For LSCM (Least Squares Conformal Maps) UV mapping.
• Conform Connected - For LSCM UV mapping.

These two commands perform the conform or unwrap on selected UVs.

• Select Perimeter
• Fit to UV, U or V
• Fit Each to UV, U or V
• Rotate Connected to Grid, U or V
• Select Pinned UVs: Selects previously pinned vertices.
• Toggle Pinned UVs: Toggles pinned vertices on or off. Allows you to pin points in a UV map to particular spots on a poly mesh.
• Move Commands: Move to U, V, Move Center to U, V.

Burn UV Dialog

• New Conform to Mesh Option - Unwrap an object's UVs after designating seams.

Import/Export

• STL Import and Export - Uses model units.
• Set Model Units on STL Import - Standard and custom units available on import.
• Improved Collada Import/Export - Support for bump and normal maps in import/export of Collada files.

Miscellaneous

Strata 3d CX 7.5 System Requirements:

Macintosh Minimum System Requirements

• Intel Processor(s)
• Mac OS X 10.6.8 or later
• 2GB of RAM (more highly recommended)
• 1.7 GB of available hard-disk space for install
• 1024 x 768 capable display
• Older CX Version Photoshop plug ins require Adobe CS 4 or CS 5.x. Design 3D CX no longer includes Photoshop plug-ins, but maintains tight integration with Adobe Photoshop.

Windows Minimum System Requirements

• Windows 7 or Vista recommended (64-bit preferable)
• Windows XP (some limitations, requires all latest service packs)
• Pentium 4, Athlon, Intel or better
• 4GB of RAM (more highly recommended)
• 1.7 GB of available hard-disk space for full installation
• 1024 x 768 capable display
• Older CX Version Photoshop plug ins require CS 4 or CS 5.x. Design 3D CX no longer includes Photoshop plug-ins, but maintains tight integration with Adobe Photoshop.
